Dial Test Indicator, 0.0001" Graduation, 0.008" Range, 0-4-0 Dial
Part # 09-0390TEST INDICATOR BI-DIR, 0-0.008"/0.0001"
Description
This Haas dial test indicator has graduations of 0.0001" with 0-4-0 dial numbering and a range of 0.008". The high resolution and small travel range make this indicator ideal for situations requiring extreme precision. Comes with 5/32" & 3/8" accessory stems for compatibility with different indicator holders. Jeweled bearings ensure smooth movement and longer service life compared to plain bearings. Made according to DIN2270.Download documents
Technical specifications
System of Measurement | Inch - ANSI |
Type | Dial Test Indicator |
Graduation | 0.0001 in |
Indicator Type | Horizontal |
Gauge Type | Dial |
Mount Type | Dovetail |
Range | 0 - 0.008 in |
Range Per Revolution | 0.008 in |
Dial Reading | 0-4-0 |
Dial Diameter | 1.47 in |
Dial Type | Balanced |
Stylus Tip Material | Carbide |
Stylus Tip Diameter | 0.039 in |
Stylus Length | 0.583 in |
Stylus Thread | M1.4-0.3 |
Bearing Type | Jeweled |
Accessory Stem Diameter | 5/32" |
Accuracy | ± 0.0005 in |
Standard | ASME B89.1.10M-2001 |
Conformance Standard | CNAS |
Weight | 0.5 lbs \ 0.2 kg |
Country of Origin | China |
Calibration Certificate (Y/N) | Y |
